Carbon Steel Online Laser Cutting

Technical designation

DC01, 1.0330, CRS CR4, St 12 (Thicknesses from 0.5mm to 3mm)

DD11, 1.0038, StW22 (Thicknesses from 4mm to 15mm)

RAEX 400 (2mm)

Available thicknesses

0.5 mm
0.8 mm
1.0 mm
1.2 mm
1.5 mm
2.0 mm
2.5 mm
3.0 mm
4.0 mm
5.0 mm
6.0 mm
8.0 mm
10.0 mm
12.0 mm
15.0 mm

Alloys

Carbon Steel – DC01

Carbon Steel – DD11

Carbon Steel – RAEX

Finishes

Unfinished, Vibrated and Sandblasted.

Main features

Cold rolled supply for thicknesses from 0.5 mm to 3 mm and hot rolled (pickled) for thicknesses from 4 mm to 15 mm.
Ease of forming using tools, both alloys are good for welding operations.
Great properties for low cost.
Surface finish and thickness tolerance for alloy DC01: EN 10131, for DD11: EN 10111.
RAEX 400 wear-resistant steel available for applications requiring high abrasion resistance, extended service life, and excellent performance in demanding environments.

Appearance of Carbon Steel Finishes

Carbon Steel
Unfinished DC01 or DD11

Unfinished factory-source finish. Front side can contain smooth scratches. Back Side can contain burrs and scratches from cutting process. Back-Side deburring process available in part configurator.

Carbon Steel
Vibrated DC01 or DD11

Unfinished variant with vibration process, it is applied on both sides of the part with a smooth grain.

Carbon Steel
SandBlasted DC01 or DD11

Unfinished variant with sandblasting process, it is applied on both sides of the part. We use glass microspheres as abrasive.

Carbon Steel
RAEX 400

RAEX 400 wear-resistant steel provides outstanding abrasion resistance while maintaining good weldability and workshop performance.

Carbon Steel

– Magnetic, dark, a tough guy, the king of the industry.

Carbon steel stands out for its ease of being cold formed , welded, machined and its good behavior to be shaped . Available with cold rolled for thicknesses from 0.5mm to 3mm and hot rolled (pickled) for thicknesses greater than 3mm.

Get a fine, smooth finish with the Vibrated Carbon Steel variant, free from oils and deep marks.

We have the SandBlasting variant, designed to clean both faces of the part and leave a homogeneous finish, perfect for subsequent painting jobs.

For applications requiring exceptional wear resistance, RAEX 400 is available. This high-strength wear-resistant steel, with a nominal hardness of 400 HBW, is specifically designed for components exposed to abrasive conditions. It offers an excellent balance of wear resistance, toughness, and good weldability, helping to extend the service life of parts operating in demanding industrial environments.

This material can oxidize or generate dark tones on its surface over time. Its protection is recommended for aesthetic applications (varnish, lacquer …)

The most common applications of Carbon Steel are industrial in general; parts for machinery, vehicle parts, structures for the construction projects, maker projects – DIY, signages, decorative letters and all kinds of parts where you look for a material resistant, good toughness and an affordable material.
